Different liquids have different surface tension, while the liquid flows through the orifice, the smaller the surface tension, the faster the rate adopted.
When mixed with different liquid into the separator, first enter coalescing filter, coalescing filter has a multi-layer filter media, increasing its aperture layer by layer.
Model | unit | LYC-25J-*/** | LYC-50J-*/** | LYC-100J-*/** | LYC-150J-*/** | LYC-200J-*/** | LYC-400J-*/** | ||
---|---|---|---|---|---|---|---|---|---|
Rated flow | L/min | 25 | 50 | 100 | 150 | 200 | 400 | ||
Temperature | ℃ | 25-80 | |||||||
Recommended viscosity | CSt | 10-120 | |||||||
Rated pressure | MPa | 0.6 | |||||||
The original pressure loss | MPa | ≤0.01 | |||||||
First filtration precision before pump | μm | 100 | |||||||
Secondary filtration accuracy after pump | μm | 10,20,40 | |||||||
Third filtration accuracy after pump | μm | 3,5,10 | |||||||
Voltage | V | Three-phase AC380V Two-phase AC220V | |||||||
Motor Power | KW | 0.75 | 1.1 | 2.2 | 4.0 | 5.5 | 13.0 | ||
Weight | Kg | 150 | 200 | 300 | 520 | 860 | 860 | ||
Dimensions | mm | 1200x820x1250 | 1350X820X1400 | 1740x980x1450 | 1800x1000x1540 | 1840x1050x1780 | 3180X1600X2000 |
Particulate filtration system: High-efficiency filter for filter media, large filtration area design, can effectively filter out impurities in very fine particles, so that the oil reached a high of cleanliness.
Coalescing systems: By coalescing system consists of a set consisting of coalescing filter, coalescing filter uses a unique polar molecular structure, oil free water and emulsified water through the filter after coalesce into larger droplets and then rely on the force of gravity settlement to the water storage tank.
Separation system: Separation filter separation system by special hydrophobic material, when the oil through the filter, the water droplets in the outer surface of the filter is blocked, the mutual coalescence until settling by gravity to the storage tank.
Drainage system: Separated water stored in the water storage tank, when the height of the interface to reach the set value, the valve opens the water discharge, until reduced to below the liquid surface, closing the valve, stop drainage.
Fifth-grade fine filter media using dirt holding capacity and great precision filter, which can safely and efficiently purify the oil.
Application:
Turbine oil and transformer oil purification
The removing water and impurities of hydraulic oil lubrication system
Access hydraulic lubrication system, comprehensively improve the cleanliness of the system
Power plant
Petrochemical
Machine made
Traffic
Metallurgical Mine
Lifeierte oil machine can produce 2000 sets of oil filtering equipment and other fluid purification equipment every year. We are one of the global competitive companies focusing on the research and manufacture of high-tech oil purifiers. The equipment is exported to nearly 50 countries all over the world! Provide online technical support and on-site service engineering to support customers' operational needs.
We provide various oil filter models. Our product sizes and materials are customized according to needs, and the capacity ranges from less than 1200L/H to 24000L/H.
→1. We are a manufacturer of oil purifiers, factory direct sales, no intermediate links, competitive prices.
→2. Our equipment is imported accessories, and the quality of the products produced is stable.
→3. To ensure on-time delivery, we can provide the best quality service, transportation, document preparation, etc.
→4. We will answer your inquiry within 24 hours.
→5. With more than 12 years of R&D experience and a professional technical team in the oil filter industry, our customers feel relaxed and happy when working with us.
