Advantages of oil filter elements:
1. Effective control of pollutants
The stainless steel filter element is used to filter large mechanical impurities in the oil. It has a simple structure, large oil passage capacity and low resistance. It is used to filter out solid particles and colloidal substances in the working medium, and can effectively control pollutants.
2. Can be cleaned repeatedly + large amount of dirt holding + long service life
The filter material of the stainless steel filter element is made of stainless steel braided mesh or copper mesh, which can be cleaned and used repeatedly. The fibers are not easy to detach, and the filtration efficiency is high.
How to choose the oil filter element:
1. Import and export path
In principle, the diameter of the inlet and outlet of the stainless steel filter element should not be smaller than the inlet diameter of the matching pump, which is generally consistent with the diameter of the inlet pipeline.
2. Nominal pressure + pore size selection
The pressure level of the stainless steel filter element is determined according to the highest pressure that may occur in the filter pipeline, mainly considering the particle size of the impurity to be intercepted, and determined according to the process requirements of the medium.
3. Filter element material
The material of the stainless steel filter element is generally selected to be the same as that of the connected process pipeline. For different service conditions, cast iron, carbon steel, low alloy steel or stainless steel filter elements can be considered.
4. Filter element resistance loss
The pressure loss is calculated according to the actual medium. The normal operation of the system cannot be affected by the installation of filter elements. The number of filter elements can be increased according to the situation to reduce the pressure loss.
